Chapter 6 Method of Wiring Connections for 16 Channels Signal Processor
CI-16-ASP-485 for Power, Video and Data (RS485) Transmission
Transmission of Power, Video and Data using Cat.5 Cable
or in combination with Bell Cable
Fig. 6.1
POWER AC/DC ADAPTER
Optional wire for Data Tansmission (for some models)
Data
PTZ Camera
Video Signal
A pair of bell cable/
Unshielded twisted pair
cable/Cat.5 cable
(UP TO 2000m)
POWER AC/DC ADAPTER
Video Signal
Power
TV monitor
Signal
Processor
Mixer
