1 Introduction of 2Y-LINK Technology 6-7
2 Features of 16 Channels Signal Processor CI-16-ASP-485 8
3 Specifications of Signal Processor CI-16-ASP-485 and
Associated Mixers
9-10
4 Product Overview: 11-22
4.1 Signal Processor CI-16-ASP-485 11-22
4.2 Push-Fit and Pig-Tail Mixers 13
4.3 Accessories for Easy of Installation 14-20
4.4 Wiring Selection 21-22
5 Methods of Wiring Connections for 16 Channels Signal
Processor CI-16-ASP-485 for Power and Video Transmission
23-32
5.1 For Power and Video Transmission USING CAT.5
CABLE (One Cat.5 Cable for four Cameras)
23-25
5.2 For Power and Video Transmission USING CAT.5
CABLE and IN COMBINATION WITH BELL CBLE
(One Cat.5 Cable for four Cameras)
26-28
5.3 For Power and Video Transmission USING CAT.5
CABLE (One Cat.5 Cable for one Cameras)
29-30
5.4 For Power and Video Transmission USING BELL
CABLE
31-32
6 Method of Wiring Connections for 16 Channels Signal
Processor CI-16-ASP-485 for Power, Video and Data (RS485)
Transmission
33-39
6.1 For Power, Video and Data Transmission Using Cat.5
cable or in combination with bell cable
34-36
6.2 Transmission of Power, Video and Data for High Power
PTZ Camera (power > 8 W) with Isolator Using Cat.5
cable or in combination with bell cable
37-39
7 Brightness / Sharpness (Colour) Switch Adjustment 40-44
8 How to mount the Signal Processor to 19” Rack 45
9 Trouble Shooting 46
