LinkBuilder Hub Configuration Guide 11
Highlights
3Com’s stackable Ethernet hubs can
provide a cost-effective network addi-
tion with full segmentation capabili-
ties and the benefits of 3Com’s LAN
Security Architecture. This solution is
also an option for a smaller network
where cost is a concern.
The slide-in LinkBuilder FMS II
Bridge Management Module lets you
segment the network, manage both
hub and bridge operations, and run
Spanning Tree Algorithm (STA) for
redundant links. It features a full
IEEE 802.1d transparent bridge com-
plete with a 1024-address filtering
database.
If all you need is low-cost, simple
bridging without sophisticated man-
agement capabilities, the LinkBuilder
Bridge MicroModule is the ideal
alternative. Just slide this unmanaged
local bridge into the transceiver inter-
face module slot of a LinkBuilder
FMS II hub.
With either option, you get
dramatic improvements in network
performance without the need to
purchase dedicated local bridges on
each floor.
Solution 4: Bridging and LAN Segmentation
Products
LinkBuilder MSH Chassis with FDDI
Backplane (3C18041)
LinkBuilder MSH 525W Power Supply Unit
(3C18012)
LinkBuilder MSH 24-Port 10BASE-T
Repeater Module (3C18122A)
LinkBuilder MSH 4-Port Ethernet Bridge
Module (3C18600)
LinkBuilder MSH Management Module
(3C18500)
Fiber-Optic Transceiver Interface Module
(3C1206-5)
Products
LinkBuilder FMS II 24-Port TP Hub
(3C16671)
LinkBuilder FMS II Telco Hub (3C16672)
LinkBuilder FMS II Fiber Hub (3C16665)
LinkBuilder FMS II Bridge Management
Module (3C16040)
Redundant Power System (3C565047)
CAD workstations
CAD
server
NetWare
®
users
NetWare 
department
server
CAD workstations
CAD
server
Rx Tx
Rx
loss
LAN Extension
LinkBuilder FMS II Bridge
Management Module
