3Com Router 3000 Series User Manual

Interface Attributes The Router 3015 provides a console port, an AUX port, a 10/100M Ethernet
interface, a synchronous/asynchronous serial interface, and an ISDN U port.
Console Port
Tab le 3 lists attributes of the console port.
AUX Port
Tab le 4 lists attributes of the AUX port.
Ethernet Interface
Tab le 5 lists attributes of the Ethernet interface.
AUX Off means that the link is not connected.
Green means that the link is connected.
Flashing green means that data is being sent or received over the
AUX port.
SYSTEM Flashing green means that the system is properly working.
Always green or off means that the system is incorrectly working.
Table 2 Router 3015 LEDs (continued)
LED Description
Table 3 Attributes of the Console Port
Attribute Description
Connector RJ45
Interface standard Asynchronous EIA/TIA-232
Baud rate 9600 to 115200bps (9600bps is the default)
Services Connects with ASCII terminal
Connects with serial interfaces of the local PCs and runs the terminal
emulation program on the PCs
Command line interface
Table 4 Attributes of the AUX Port
Attribute Description
Connector RJ45
Interface standard Asynchronous EIA/TIA-232
Baud rate 300 to 115200bps
Services Modem dial-up
Backup
Protocols PPP (Point to Point Protocol)
SLIP (Serial Line Internet Protocol)
MP (Multilink PPP)
Table 5 Attributes of the Fast Ethernet Interface
Attribute Description
Connector RJ45
3Com Router Release Notes for V1.20
16
