3Com Router 3000 Series User Manual

NEW HARDWARE
This release includes new hardware for the Router 3000 and Router 5000 series
routers:
Router 3000 series router:
■ Router 3015
Router 5009 smart interface card (SIC):
■ 2-Port ISDN BRI U SIC
Router 5231, 5640, and 5680 multifunctional interface modules (MIMs):
■ 4-Port Synchronous/Asynchronous Serial MIM with X.21 Support
■ 4-Port E1/CE1/PRI MIM
■ 1-Port Channelized E3 MIM
■ 1-Port Channelized T3 MIM
Router 3015 Figure 1 illustrates the Router 3015 router.
Figure 1 Router 3015
Figure 2 illustrates the back panel of the Router 3015.
Figure 2 Back Panel of the Router 3015
Power LED
100M Ethernet LED
Serial LED
BRI LED
AUX LED
System LED
OFF ON
DC12V
CON AUX 100M ETH SERIAL BRI
Power
switch
Power
input
socket
CON
port
AUX
port
100M
Ethernet
port
SERIAL0
Grounding
screw
BRI port
3Com Router Release Notes for V1.20
14

3Com Router 3000 Series Specifications

General

Brand	3Com
Model	Router 3000 Series
Category	Network Router
Language	English
