Approved By: Date: <6/14/2016> Page 8 of 11
WI XXXX-xxxxxx– 3DP Moving the Printer
Step 7: Insert lift rod.
From the rear of the machine carefully insert the lift rod in the square hole.
With an assistant guiding the rod push it through the machine and out the front hole.
