3M Overhead Projector 2660 Illustrated Parts Breakdown
© 3M IPC 2001 5
Figure 1. Head Assembly Spare Parts
Figure 1. Head Assembly Spare Parts
Item
No.
3M
Part Number
Description Qty.
1 XO-0038-9281-7 Mirror Assembly 1
2 XO-0038-9280-9 Projection Lens Assembly 1
3 XO-0038-9283-3 Condenser Lens Assembly 1
4 XO-0038-9279-1 Lamp Bracket Assembly 1
5A 78-6969-9246-6 Lamp, FNT, 24V, 275W (100-127V machines) 2
5B 78-6969-9357-1 Lamp, EHJ, 24V, 250W (220-250V machines) 2
1
2
3
45
** NOTE:
Mounting hardware is only available
in the Small Parts Kit, Section 7.
