3M APIF100 - Page 32

SECTION 7: QUICK CONNECT BYPASS
Part Number V3006
Reference No. Part No. Description Quantity
1 V3151 Nut 1” Quick Connect 2
2 V3150 Split Ring 2
3 V3105 O-ring 2
7-6
1
2
3
3
1
2
V3151 1” Quick Connect Nut 2
V3150 Split Ring 2
V3105 O-ring 215 2
V3191 Vertical Bypass Adapter 1
Not Shown Part# V3191-01 Vertical Bypass Adapter
