Model C960 Controls and Indicators
3M 2000 May
For dual–lane systems, press and hold the T2 (Talk Lane 2) switch to talk to the
customer at the menu sign in lane 2. Release the switch to listen.
For single–lane systems, T2 can also be used to talk to lane 1.
Press and hold the Page switch to talk to internal personnel without being heard
by the customer at the menu sign. Release the switch to listen. (With the switch
released, you can hear both menu sign customers and internal paging.)
For duplex systems, press the talk lock switch once to talk and listen to the
customer. This enables hands–free operation.
Push the battery release up and hold it there while sliding the battery out of the
headset housing.
This rechargeable battery provides power to the headset.
This jack accepts the programming cable from the base station to allow the
headset to be programmed to the same channel as the base station.
The microphone sends the headset operator’s voice to the menu sign or other
headset operators. The filter is a protective cover for the microphone.
The earphone is a speaker that broadcasts the voice from the customer at the
menu sign or from other headset operators. The replaceable earpad covers the
earphone and cushions the operator’s ear to provide comfort.
The headband pads cushion the operator’s head to provide comfort.
The headband adjustment slide is used to increase or decrease the size of the
headband.
The headband width adjustment tab is used to increase or decrease the headband
pad pressure.
6 T2 (Talk Lane 2)
8 Talk Lock Switch
11 Headset
15 Headband
16 Headband Width
