3M DP1 Series - DP3 XX Manifold Replacement Parts Listing

20
Nomenclature Des Pièces High Flow Series / High Flow Series – Teileliste / Elenco di
Identicazione Delle Parti High Flow Series / Lista de Identicación de Piezas de la Serie de
Alto Flujo / Onderdelenlijst Van de High Flow-Reeks /
ハイフローシリーズ部品確認リスト
ハイフローシリーズ部品確認リスト /
高流量系列部件标识列表
高流量系列部件标识列表
High Flow Series Parts Identication List
DP3XX Manifold Replacement Parts Listing
Item 3M ID Part no. Description
1 70-0202-2942-6 6228403 DP3XX Triple Manifold
2 70-0203-5423-2 60-2333700 Vent Valve
3 See catalog Replacement Cartridges
4 70-0203-3011-7 50-93701 Pressure Gauge
5 70-0203-3047-1 50-93737 Clip
6 70-0203-3022-4 50-93712 O-Ring
7 70-0202-2973-1 6225005 Inlet tting kit – left rear
8 70-0202-2974-9 6225006 Outlet tting kit – left front (Cold Beverage)
9 70-0202-2975-6 6225007 Outlet tting kit – right front (Ice/Coee)
10 N/A N/A 3/4" x 3/4" ball valve
11 Inquire 5617501 Retainer Kit
12 70-0203-1902-9 5582113 HF8-S Replacement Cartridge
