2.6 TECHNICAL INFORMATION, MAIN UNITS DC2811, DC2812, DC2815
Frequency range: 1880 – 1900 MHz
Operation mode: Duplex
Output power: Max. 250 mW,
average 10 mW (portable) / 120 mW (base)
Current consumption: Base/Portable unit
DC2812, DC2815
as base typ. 320 mA (4 portables system)
as portable; typ. 160 mA in talk mode
Portable unit DC2811 40 mA (listen only) / 60 mA (talk mode)
Working range: Outdoors typ. 250 m (line of sight)
Indoors typ. 50 m
Battery life cycle: With rechargeable battery
Peltor DC2033
approx. 6 h (base unit)
approx. 40 h (portable unit)
With 6xAA additional 2100
mAh NiMH batteries in DC2032
approx. 18 h (base unit)
approx. 18 h (base unit)
Usage temperature: -26°C to +55°C
Storage temperature: -55°C to +70°C without batteries
(Store batteries according to battery manufacturer´s
instructions)
Weight excl. batteries: Incl. battery pack DC2033 310 g (DC2812, DC2912)
Microphone types: Carbon 300 mV typ. Medium power feed enabled; 20mA
Electret 20 mV typ. Low power feed enabled; 1mA
Dynamic 4 mV typ.
Low impedance 0,4 mV typ.
Headset connector: Peltor J11, type M9177/4-1 (NEXUS TJT-102)
3. POWER SUPPLY
A main unit can generally be power supplied with a rechargeable battery pack DC2033 in the battery compartment.
The external battery carrier DC2032, for 6 or 3 type AA batteries, can also be used to increase the usage time of the unit.
Also, in low or high temperatures (below 5°C or above 45°C), where the NiMH batteries do not have full capacity, a main
unit can be continuously power supplied in a power supply holder DC2068 with a mains adapter DC2061
NOTICE! See below concerning the mandatory mains adapter DC2061, which is included in the package at delivery of the
power supply/holder DC2068!
When the energy in the battery is low, voice messages announce that it is time to charge the batteries or, when appropriate,
to change batteries.
! Themessage“BATTERY LOW”indicatesthattheenergyinthebatteryislowandyoushouldchargeorchangebattery
assoonaspossible.
!Themessage“BATTERY EMPTY”indicatesthattheenergyinthebatteryisveryclosetoemptyandtheunitwill
automaticallyswitchoff!
