Frame
Top tube
Down tube
Seat tube
Head tube
Chain stay
Seat stay
Seat
Seat post
Seat post clamp
Dropout
Derailleur cassette
Quick release
Rear derailleur
Front derailleur
Chain
Chain ring
Crank arm
Pedal
Stem
Handlebars
Brake lever
Shifter
Headset
Shifter cable
Brake cable
Fork
Disc brake caliper
Brake disc
Thru axle
Wheel:
Front wheel hub
Spoke
Tire
Rim
Valve
Bicycle parts
6
5
4
4
3
3
2
2
1
1
5
6
If you leave this page unfolded when you read this guide, you can immediately recognise which part of the bicycle is being referred to.
