Chapter 1. Getting Started
6 3ware 9650SE Serial ATA RAID Controller Installation Guide
Figure 4. 12-Port 3ware 9650SE-12ML Serial ATA RAID Controller
Figure 5. 16-Port 3ware 9650SE-16ML Serial ATA RAID Controller
Ports:
8 thru 11
4 thru 7
0 thru 3
I
2
C connector
Holes for
battery holder
BBU connector and hole for post
Heat sink
LED Connectors
Ports:
12 thru 15
8 thru 11
4 thru 7
0 thru 3
I
2
C connector
BBU connector and hole for post
Heat sink
LED Connectors
Holes for
battery holder
