9650SE RAID Controller Card Models
www.3ware.com 5
Figure 2. 4-Port 3ware 9650SE-4LPML Serial ATA RAID Controller
Figure 3. 8-Port 3ware 9650SE-8LPML Serial ATA RAID Controller
Ports:
0 thru 3
I
2
C connector
BBU connector and hole for postSlots for battery
holder
Heat Sink
LED Connector
Ports:
4 thru 7
0 thru 3
I
2
C connector
BBU connector and hole for post
Slots for battery
Heat Sink
LED
Connectors
