QSG-002 / 01-03-2017
7
ì PoE SWITCH
1. Using PoE, run a standard network cable (Cat 5 or Cat 6) directly
from the Ethernet switch to the eIDC.
2. Put an Uninterruptable Power Supply (UPS) at the switch to
provide redundant power.
3. Go to Determine the eIDC IP Address on page 8 and complete the
installation.
î=NON-PoE WITH MIDSPAN PoE INJECTOR
1. Using non-PoE, run a standard network cable (Cat 5 or Cat 6)
directly from the Ethernet switch to the Midspan PoE Injector.
2. Put an Uninterruptable Power Supply (UPS) to both the Midspan
PoE Injector and the switch to provide redundant power.
3. Run another standard network cable (Cat 5 or Cat 6) from the
Midspan PoE Injector to the eIDC Ethernet connector.
4. Go to Determine the eIDC IP Address on page 8 and complete the
installation.
ï=NON-PoE SWITCH
1. Using non-PoE, run a standard network cable (Cat 5 or Cat 6)
directly from the Ethernet switch to the eIDC.
2. Wire a redundant 24 VDC power supply to the eIDC and then apply
power.
3. Go to Determine the eIDC IP Address on page 8 and complete the
installation.
ñ=NON-PoE WITH POWER INJECTOR
1. Using non-PoE when only a small number of ports will require PoE,
run a standard network cable (Cat 5 or Cat 6) directly from the
Ethernet switch to the Power Injector.
2. Wire a redundant 24 VDC power supply to the Power Injector and
then apply power.
NOTE: With PoE, the external power supply connected to the
Power Injector may not be required. If both a PoE-enabled switch
