PAGE 5
PRODUCT OVERVIEW
SPECIFICATIONS
Supply Voltage:
24 to 240 VAC/VDC
Supply Fusing:
Supply to be fused at 500mA maximum. Note: fuse must be 1500A capable.
1 fuse per sensor MUST be used.
Switching Capacity:
50 mA maximum
Saturation Voltage: 5.5 Volts maximum (output on)
Leakage Current: 1 mA maximum (output off)
Ambient Temperature: 5°F (-15°C) to +122°F (+50°C)
Output State:
FET
Contact closed above 0% set speed
Contact opens when zero speed detected
Sensing Range:
6 mm (15/64”) maximum on ferrous metal at 77°F (25°C)
5 mm (13/64”) maximum on non-ferrous metal at 77°F (25°C)
Input Pulse Range: From 20 to 3,600 pulses per minute (PPM)
Start-Up Delay: 4 seconds
Trip Point: When no pulse is detected for more than 4s (zero speed condition)
Enclosure: Nylon - ISO threaded 18 mm by 1.0 mm pitch
Relative Humidity: 90% RH
LED Indicators: Blue - Target Sensed, Green - Speed Present
Connections: 2 wire; 3m long cable.
Protection: IP66
WARNING
• Rotating machinery can cause serious injury or death
• Always lockout and tagout the machine prior to installation
The M100 Stopswitch is a simple inductive proximity shaft speed monitoring device. The self-contained
unit has a single set point, which signals when the shaft has stopped rotating. It can be used for process
control, motion detection and stopped shaft indication.
An inductive sensing device located in the nose of the M100 enclosure will detect a metal target. Ideally,
the target should be a ferrous metal, but non-ferrous metal will be detected at a shorter range. Maximum
range for ferrous targets is 6 mm (15/64 in.) and for non-ferrous targets it is 5 mm (13/64 in.), assuming
a 19 mm (3/4 in.) diameter target. Smaller targets may be used but operating distances will be reduced.
The M100 Stopswitch requires no calibration and provides an output when the shaft has stopped rotating.
The unit incorporates a start-up delay of 4 seconds to allow moving parts to achieve correct speed,
thereafter, if a pulse is not received within 4 seconds an output stopped motion signal is indicated.
