3.4 Loading Label for Peel-off Mode (Option)

1. Open the peel-off module by pulling it out.

Peel-off Roller

Peel-off Panel

2. Thread the label, printing side facing up, through the label guides and place it on top

of the platen.

3. Thread the label through the liner opening, which is beneath the roller.

4. Adjust the center-biased label guides by finger to fit the edge of the label backing.

Adjustment

Roller

Peel-off panel

5. Push the peel-off panel back to the printer.

6. Close the top cover.
