MIRAGE Line Compressors Instruction Manual
1098
7
6
4
3
21
2 - 02
Mechanical pressure switch [230 V versions] (Fig. 1)
Mechanical pressure switch [MDR3 - 400V three-phase versions] (Fig. 2)
Safety valve (Fig. 3)
Non-return valve [For compressors with dryer] (Fig. 4)
Dryer [Only if model is identifi ed
with letter “E”] (Fig. 5)
3-way non-return valve (Fig. 7)
[For compressors without dryer]
2-way N.O. 1/8” solenoid valve
(Fig. 7)
Pressure gauge [Only for TOP
Line versions] (Fig. 8)
Pressure gauge [All other
versions] (Fig. 9)
Miscellaneous fi ttings
Miscellaneous accessories
Pressure reducer
with pressure gauge (Fig. 10)
