a/d/s/ PH30.2 - specifications; amplifier section; crossover section

specifications
amplifier section PH 30.2
power output 4 (watts)1 6 channel 6 x 75
3 channel 3 x 250
power output 2 (watts)2 6 x 112.5
fuse type 70 A maxi
dimensions 13" x 19 7/8" x 2"
distortion all channels driven <0.1% 20Hz to 20,000Hz
frequency response ±1dB 10Hz to 30,000Hz
signal-to-noise ratio full >90dB
bandwidth @ rated output power
damping factor @ output >150
connector full bandwidth
input sensitivity 100mV to 8Vrms for full output
input impedance 47 k
crossover section
ch 1 & 2 high-pass 12dB/octave variable 45Hz- 5kHz
h 3 & 4 high-pass & low-pass 12 dB octave variable 45Hz- 5kHz
ch 5 & 6 low-pass 12 dB / octave variable 45Hz- 5kHz
Constant Bass low-pass 12dB/octave variable 30Hz- 300Hz
1 All channels driven, continuous FTC rated 4 load, 20Hz to 20,000Hz, <0.1% THD, power input
voltage at 13.8DVC.
2 All channels driven, continuous FTC rated 2 load, 20Hz to 20,000Hz, <0.1% THD, power input
voltage at 13.8DVC.
3 All channels are selectable with infinitely variable adjustments from 45Hz to 5,000Hz with a slope
of 12dB/octave and a "Q" of .707.
21
