SETUP 11
FOR TECHNICAL QUESTIONS, PLEASE CALL 1-855-888-3598
7. Attach the Nozzle to the Wand by
pulling back the quick connect collar
and pushing the Nozzle onto the end of
the Wand. Make sure the quick connect
collar locks the Nozzle in place.
Nozzle
Wand
Quick Connect
Collar
See Figure G.
Figure G
8. Connect the water supply hose to the
water inlet connection on the Pump and
tighten the Inlet Fitting rmly by hand.
See Figure H.
The water source must be able to
provide a minimum of ve gallons of
clean, cold water per minute at 20PSI.
Only use a 5/8” inner diameter, or larger
hose that is rated to meet this capacity.
Figure H
GENERAL INFORMATION:
Fuel Use fresh high-quality unleaded gasoline (minimum 87 octane),
containing up to 10% ethanol.
Do not use fuel with high ethanol content; E15 or E85.
Oil Engine oil: Use only SAE 1 0W-30, 0.6 Quart non-detergent oil
(supplied).
Pump Oil: The pump was lubricated and sealed at the factory, and is
maintenance free for the life of the product, under normal operation. Do
not attempt to change or add oil to the pump. If the pump is leaking oil,
please call our customer service department at 1-855-888-3598.
Water Use only cold water.
Do not operate pressure washer with clogged or missing water inlet filter
screen.
Do not operate pressure washer without adequate water supply.
Pressure
Adjustment
Pressure setting is pre-set at factory.
For lowering pressure, refer to “Pressure Adjustment” on Page 18.
