A.O. Smith Cyclone BFC - 30 - Technical Specifications

Installation
20 Instruction manual BFC
3
is
3.4 Technical specifica-
tions
The appliance is supplied without accessories. Check the
dimensions (3.4.1 "Dimensions of the appliance"), gas data (3.4.3 "Gas data")
and other specifications (3.4.2 "General and electrical specifications") of any
accessories you plan to use.
3.4.1 Dimensions of the appliance
Plan and elevation of the appliance
Legend
See the table.
