1
If one is not already installed,
install a manual shuto valve
in the cold water line that
supplies the water heater. Install the
shuto valve near the water heater so
that it is readily accessible. Only use
valves that are compable with
potable water. Use only full-ow ball
or gate valves. Other types of valves
may cause excessive restricon to the
water ow.
2
Install a Thermostac Mixing
Valve. Consult the valve
manufacturers instrucons
or a qualied person.
Figure 14 - Install Thermostatic Mixing Valves
where hot water will be used.






3
For water heaters that are fed
by a solar water heang
system (or any other pre-
heang system), always install a
Thermostac Mixing Valve or other
temperature liming device in the inlet
water supply line to limit water supply
inlet temperature to 120°F (49°C).
Solar water heang systems can supply
water with temperatures exceeding
170°F (77°C) and may result in water
heater malfuncon.





1


Determine the type of water pipes in
the plumbing system. Most systems
use copper water pipes, but some
use CPVC or cross-linked polyethylene
(PEX). Use ngs appropriate for the
type of pipe in the plumbing system.
Do not use iron or PVC pipe – they are
not suitable for potable water.
2
Connect the cold water
supply using 3/4 inch (19mm)
Naonal Pipe Thread “NPT
to the cold water inlet nipple.
For ease of removing the water heater
for service or replacement, connect
the water pipes with a coupling
called a union. We recommend using
a dielectric-type union (available at
local plumbing supplier). Dielectric
unions can help prevent corrosion
caused by ny electric currents
common in copper water pipes and
can help extend the life of the water
heater.
16 • Commercial Electric Water Heater Use and Care Guide
INSTALLATION


If the plumbing system has copper
water pipes, you can solder the
water pipe connecons or use
compression ngs which don’t
require soldering. Compression
ngs are easier to install than
soldering pipe. Check with local
plumbing ocials to determine
what types of pipe materials are
suitable for your locaon. Do not
use lead-based solder.
 Do not solder pipes while
they are aached to the water
heater. The water heaters inlet
and outlet connecons contain
non-metallic parts which could
be damaged. The proper way
to connect the water heater to
copper water pipes is as follows:
Solder a short length of pipe
(about a foot or so) to a
threaded adapter using only
95/5 n-anmony or equivalent
solder. Aach the threaded
adapters to the water heaters
connecons (using thread
sealant tape or pipe joint
compound). Connect the water
pipes by soldering, keeping the
connecons at the water heater
cool with wet rags.
INSTALLATION
