A.O. Smith Z7 - A. O. Smith Z7 RO Water Purifier Overview

07
Front View
Back View
Figure 3
A. O. Smith RO water purifier
LED Display Panel Indicators
Water Level Indicator
Top Cover
LED Display Panel Indicators
Water Level Indicator
Hot Water Outlet
Main Body
Hot Water Tank
Drip Tray Cover
Normal Water Outlet
Front Cover
Removable Drip Tray
Rear Cover
Overflow water
Reject water
Feed water inlet
O I R
