A.O. Smith Z7 - Page 27

Figure 39
Figure 40 Figure 41
3. Clean the surface of water tray with a soft cloth. (Figure 39)
4. Re-attach the Drip Tray assembly into
the purifier. (Figure 41)
4. Re-attach the Drip Tray assembly into
the purifier. (Figure 40)
23
