27
Key No Req’d Description Part N°
1 2 Clamp Section 7176292
2 2 Retainer Clamp 7088033
3 1 O-ring, 2-7/8 x 3-1/4 7170296
4 1 O-ring, 13/16 x 1-1/16 7170254
5 1 O-ring, 2-3/4 x 3 7170270
6 1 Top Distributor 7077870
7 1 Rep’l Bottom Distributor 7105047
8 1 Rep’l Resin Tank Pkd 7197468
9 1 cu. ft Resin 502272
10 1 Brine Valve Assembly 7264207
11 1 Brine Tube 7152989
12 1 Tubing Assembly 7113016
13 1 Screen 7131365
14 1 Clip 7080653
15 1 Brine Valve Body 7092252
16 1 Clip 1205500
17 1 Float, Stem & Guide Assembly 7269508
18 1 Electronics Enclosure Rear 7269930
19 1 Face Plate (order decal below) 7281089
1 Decal, Face Plate 7281102
20 1 Power Cord 7250826
21 1 Rep’l PWA 7281823
22 1 Salt Lid 7281055
23 1 Cover, Top 7281039
24 1 Rim 7281047
25 1 Brinewell Cover Assembly 7155115
26 1 Wing Nut 7082150
27 1 Brinewell w/Decal 7263099
28 1 O-Ring 7003847
29 1 Screw 7148875
30 1 Rep’l Brine Tank Pkd 7287815
31 1 Hose Adaptor 1103200
32 1 Grommet 9003500
33 1 Hose Clamp 900431
