4
SPECIFICATIONS AND DIMENSIONS
52 @ 0.8
86 @ 1.7
Rated Capacities @ salt dose (°Fm³@Kg)
122 @ 4.6
Resin Quantity (Liters) 18
Rated Service Flow (L/min) 26
pressure drop @ service flow (BAR) 0.6
Max Flow rate to the drain (l/min) 11
Max hardness (°F) 162
Max Clear water Iron ( PPM) 5
Tank Size ( inch) 10*21
Valve connections (inch) 3/4
Capacity salt tank (Kg) 45
Operating water pressure limits (Bar)) 1.4 to 8.6
Operating Water temp limits (°C) 4-49
electrical rating Transformer 240 VAC to 24 V AC
