SPECIFICATIONS :
Page 8
Specifications :
Rated amperage : 500A
Rated Voltage : 100~1000VDC
Conductor Material : Silver plated copper
Contact resistance : 5 mΩ
Shell Material : UL-94-V0 PA66
Storage Temperature : -30°C to 85°C
Operating Temperature : -40°C to 50°C
Security : Dual temperature sensor switch
Sealing gasket : Silicon rubber
Locking : Dual locking mechanism is one.
Security : The vast majority of vehicles lock
chargers and adapters by their charge port.
Degree of protection : IP54 (mating) & IP67
(enclosing)
WARRANTY :
Enjoy a 12-month warranty against manufacturing defects.
Note: Warranty doesn't cover misuse, mishandling, negligence,
accidents, or modifications.
Our warranty only covers manufacturing defects.
Consult the warranty section on our website for more informations.
