value of the inlet velocity pressure for a RotoClone Arrangement A of the same
size. Collected dust and water are continuously discharged as a slurry through a
single hopper drain.
3.4 Sizes
The RotoClone W Arrangement A is available in 12 sizes and the RotoClone
W Arrangement D is available in 7 sizes as outlined in the table below. The table
also shows the inlet dust load range for each Arrangement and the airflow range
from the smallest to largest size. The RotoClone W Arrangement A sizes represent
the inlet diameter of the collector in inches (1 inch = 25.4 mm), e.g. the Size 12
has a 12 inch inlet diameter. See 3.6 for a listing of sizes with weights.
Arrangement
*
Inlet Dust Loading
Sizes
Offered
*
Airflow Range (Depending on
Size)*
Grains/ft
3
mg/m
3
ft
3
/ minute
m
3
/ hour
A
0 to 2
0 to 4576
12.0
1000 to
50,000
1699 to 84950
D
0 to 10
0 to
22,884
7.0
1000 to
15,000
1699 to
25,485
 Review the purchase order and the product documentation supplied for the
arrangement, size and airflow rating of the equipment supplied.
3.5 Filter elements
There are no disposable filter elements associated with the standard
RotoClone W. Occasionally, but rarely, after-filters may be supplied to provide
additional filtration efficiency on very small particulates. Review the purchase
order and the product documentation supplied for details of any after-filters.
