Lubrication Interval
RotoClone
Size
Cu. In.
Grease
6mos
4mos
2mos
Max Operating Speed
(RPM)
8
0.3
2400
3600
5000
10
0.3
2400
3600
12
0.4
2000
3000
14
0.8
1700
2500
16
0.8
1450
2200
20
0.8
1450
2200
24
1.2
1300
1900
27
1.7
1200
1800
30
2.3
1100
33
3.1
1000
36
3.1
1000
45
4.3
900
Grease shaft seal at same time as bearings. Water leakage is an indication of
insufficient grease.
11.3 Nozzles and Strainer
Flush out strainer periodically and inspect spray nozzles for proper water
delivery and pattern. Since water quality varies, a monthly inspection, for the first
year of operation is recommended, in order to determine a maintenance schedule.
On a Food Quality RotoClone W, special attention should be paid to the spray
nozzles and areas where there are quick opening access doors. These areas often
require more frequent cleaning. It is recommended that a preventative
maintenance schedule be developed specific to each W RotoClone.
11.4 RotoClone Inlet (Arr. A)
Open inspection door at RotoClone inlet connection and remove any
accumulation in the inlet at the border line of the wet and dry section. The
frequency of cleaning varies for each installation and must be determined by
frequent inspection when RotoClone is first placed in service. Clean out before
accumulation obstructs one-tenth of cross section area or inlet connection. Clean
sludge from RotoClone inlet door before closing.
