RotoClone® W

this document contains, without permission of American Air Filter

Company, Inc., is prohibited. RotoClone, AAF, REDClean, REDFiltration,

and Reliable Efficient Durable are registered trademarks of American Air

Filter Company, Inc. d/b/a AAF International.

RotoClone W Parts List:

1. Expansion Chamber Assembly

2. Impeller Shaft

3. Bearing, Shown on

4. Water Cone Assembly

5. Inlet Cone Assembly

6. Impeller Assembly

7. Inlet Connection

8. Cone Spray Nozzle

9. Piping Assembly

10. Monarch Figure 624 Nozzle

11. Housing Assembly

12. Outlet Connection

13. Impeller Hub

14. Hex. Head Cap Screws

15. Impeller Hub Cap

16. Taper Lock Bushing

17. Key

18. Seal Housing Assembly

19. Shaft Seal 2

20. Spacer

1. Standard RotoClone, sizes 16 and smaller, may have inlet, outlet, and

expansion chamber welded to housing in lieu of flanged and bolted

connection.

2. Seal consists of two Buna-N pieces and two garter springs. Radial cuts

should be sealed with silicon caulk when installing new seal.
