INDEX NAME
DATA
TYPE
NOTES
29 Kgain[2] float
30 Kgain[3] float
31 Kgain[4] float
32 Kgain[5] float
33 Reserved float
34 Reserved float
35 Reserved float
36 Reserved float
37 Reserved float
38 Reserved float
39 ValveTbl[0][open] float Index 0: Valve actuation. Must be 0.0.- Do Not Alter
40 ValveTbl[0][valve value] uint Index 0: Valve: D/A value - Do Not Alter
41 ValveTbl[1][flow] float Index 1: Actual valve opening in % FS. Do Not Alter
42 ValveTbl[1][valve value] uint Index 1: Valve D/A counts corresponding to flow. Do Not Alter
43 ValveTbl[2][flow] float Do Not Alter
44 ValveTbl[2][valve value] uint Do Not Alter
45 ValveTbl[3][flow] float Do Not Alter
46 ValveTbl[3][valve value] uint Do Not Alter
47 ValveTbl[4][flow] float Do Not Alter
48 ValveTbl[4][valve value] uint Do Not Alter
49 ValveTbl[5][flow] float Do Not Alter
50 ValveTbl[5][valve value] uint Do Not Alter
51 ValveTbl[6][flow] float Do Not Alter
52 ValveTbl[6][valve value] uint Do Not Alter
53 ValveTbl[7][flow] float Do Not Alter
54 ValveTbl[7][valve value] uint Do Not Alter
55 ValveTbl[8][flow] float Do Not Alter
56 ValveTbl[8][valve value] uint Do Not Alter
57 ValveTbl[9][flow] float Index 9: Valve fully open. Must be 1.0- Do Not Alter
58 ValveTbl[9][valve value] uint Index 9: D/A count for a fully open valve. Must be 4095.- Do Not Alter
59 AutoTune Time Constant uint Do Not Alter
