Aalborg DFC User Manual

CALIBRATION TABLE: GAS DEPENDENT VARIABLES
39
INDEX NAME
DATA
TYPE
NOTES
100 GasIdentifer char[27]
101 FullScaleRange float
102 StdTemp float
103 StdPressure float
104 StdDensity float
105 CalibrationGas char[27]
106 CalibratedBy char[20]
107 CalibratedAt char[20]
108 DateCalibrated char[10]
109 DateCalibrationDue char[10]
110 PID_Kp float
111 PID_Ki float
112 PID_Kd float
113 SensorTbl[0][Sensor Value] uint Index 0: Must be 120 (zero value)
114 SensorTbl[0][Flow] float Index 0: Must be 0.0 (zero PFS)
115 SensorTbl[1][Sensor Value] uint A/D value from sensor.
116 SensorTbl[1][Flow] float Actual Flow in PFS.
117 SensorTbl[2][Sensor Value] uint
118 SensorTbl[2][Flow] float
119 SensorTbl[3][Sensor Value] uint
120 SensorTbl[3][Flow] float
121 SensorTbl[4][Sensor Value] uint
122 SensorTbl[4][Flow] float
123 SensorTbl[5][Sensor Value] uint
124 SensorTbl[5][Flow] float
125 SensorTbl[6][Sensor Value] uint
126 SensorTbl[6][Flow] float
127 SensorTbl[7][Sensor Value] unit
128 SensorTbl[7][Flow] float
