WSHP Series Feature String Nomenclature
Unit Configuration
:
Accessory Options
Gen
Major Rev
Size
Series
Minor Rev
Voltage
Eff. Level
Comp Style
Loop Type
Coil Type
Heat Type
Heat Staging
1
2
3A
3B
4
5
6A
6B
7
8
9
10
11
12
13
14
15
16
WH A - 024 - C - 0 - 3 - 1 - 0 0 0 - 0 0 : 0 0 -
0
A
-
0
0
-
0
0
-
0
0
0
0
0
-
0
0
0
0
0
3A: Filter Rack*
0 = Open Return – Slide-Out Filter Rack
D = 4-Sided 2” Filter Rack - Return Duct Flange and
Access Panel
E = 4-Sided 2” Filter Rack + High MERV Filter Seal
- Return Duct Flange and Access Panel
F = 4-Sided 4” Filter Rack + High MERV Filter Seal
- Return Duct Flange and Access Panel
J = 4-Sided 1” Filter Rack + Access Panel - Return
Duct Flange and Access Panel
K = 4-Sided 1” Filter Rack + High MERV Filter Seal
- Return Duct Flange and Access Panel
* 1” Filter Rack for A Cabinet Only
3B: Filters
A = 2” MERV 8 Filter
B = 4” MERV 11 Filter
C = 4” MERV 13 Filter
D = 4” MERV 14 Filter
E = 1” MERV 8 Filter
F = 1” MERV 11 Filter
G = 1” MERV 13 Filter
4: Refrigeration and Dehumidification Options
0 = Standard
A = ECM Fan Speed Dehumidification
B = On/Off Hot Gas Reheat Dehumidification
5: Service Disconnect
0 = Standard - 5 KAIC
A = Non-Fused Service Disconnect - 30 Amp
B = Non-Fused Service Disconnect - 60 Amp
D = 5 KAIC Standard / 100 KAIC w/ Field Installed
Fusing
E = 100 KAIC Fusing
F = 100 KAIC Fusing w/ Fused Disconnect - 30 Amp
G = 100 KAIC Fusing w/ Fused Disconnect - 60
Amp
6A: Control Sequence
0 = Terminal Block for Thermostat + Pioneer Silver
Controller
A = Terminal Block for Thermostat + Pioneer Silver
Controller + Expansion Board
B = Pioneer Gold Controller
6B: Control Options
0 = Standard - No Communication
7: Cabinet Options
B = Closed Cell Neoprene Foam Cabinet Insulation +
Stainless Steel Drain Pan
C = Low Sound Package - Closed Cell Neoprene
Foam Cabinet and Blower Insulation + Compressor
Sound Blanket + Stainless Steel Drain Pan
0 = 1” Foil Face Cotton Fiber Cabinet Insulation +
Stainless Steel Drain Pan
A = Low Sound Package – 1” Foil Face Cotton Fiber
Cabinet and Blower Insulation + Compressor Sound
Blanket + Stainless Steel Drain Pan
E= Closed Cell Neoprene Foam Cabinet Insulation +
Mass Loaded Vinyl + Stainless Steel Drain Pan
8: WSE
0 = Standard - None
B = Waterside Economizer + 3-Way Motorized
Valve
9 & 10: Blank
00 = Standard - None
11: Code Options
0 = Standard - ETL USA Listing
B = ETL USA + Canada Listing
12: Shipping Options
0 = Standard - Sheet Metal Pallet with Forklift Slots
and AAON Blue Shrink Wrap
13: Cabinet Access
0 = Bottom Service Access Panel
A = Standard - No Bottom Access
14 & 15: Blank
00 = Standard - None
16: Cabinet
0 = All Aluminum Cabinet Construction
