Aaronia BPSG 6 - Hardware

HW © 2015 Aaronia AG, DE-54597 Strickscheid, www.aaronia.com, mail@aaronia.de 8
Manual RF Signal-
Generator
3. Hardware
3.1. Connectors (BPSG 4 and BPSG 6)
Front view:
Backview:
Power Supply Connector
Status LED
10MHz Reference clock
input (max 3,3V; optional)
Charge
-
LED
ON/OFF Switch
USB Connector
(no charging
capability)
RF Output
