3.2. Connectors (BPSG 4 OEM and BPSG 6 OEM)
Backview:
USB Connector
2x4 Connector
(2,00mm Pitch)
RF Output
90° Housing Brackets & Screws
Installed Brackets
2x3 Connector
(2,54mm Pitch)
10MHz Reference clock
input
(max 3,3V; optional)
