Manual Stair Robot SR1750 HE
Publication: 29-07-04
AATA INTERNATIONAL B.V.
3.2. Turntable
•
The turntable is a circular piece of
equipment Ø 610 mm, h. 40 mm.
constructed out-of two disks of
block board with hard-plastic
surface to eliminate friction. It is
used to alter the direction of travel
for the (loaded) StairRobot. There
are finger grips on either side for
easy lifting or carrying.
3.3. Winch
•
The winch is designed to fit into the lifting platform of the stairrobot. With the winch a
load can be pulled onto the platform with a minimum amount of effort
Page 10 of 28
