AATA SR1750 HE - 1 Technical Data

Manual Stair Robot SR1750 HE
Publication: 29-07-04
AATA INTERNATIONAL B.V.
1. Technical data SR 1750 HE
Description Value Units
Speed 3 Metres p/minute
Lifting capacity max. 1000 Kg.
Maximum angle Max. 45 º Degrees
Weight 175 Kg.
Weight including standard accessories 232 Kg.
Colour ~~ ~~
Length 1185 Mm
Width 720 Mm
Height 320 Mm
Length loading ramp 1180 Mm
Width loading ramp 720 Mm
Drive-motor: single phase low noise AC
Thermal cut-out
Drive-motor capacity 0,75 KW
1 Hp
Drive-motor power 220 or 110 V
Hydraulic-motor: single phase low noise AC
with thermal cut out
Hydraulic-motor capacity 0,375 KW
0,5 Hp
Hydraulic-motor power 220 or 110 V
Hydraulic-pump: built directly on the hydraulic
Motor
Hydraulic-pump capacity 0,8 ltr/per minute
Action pressure max. 100 Bar
Capacity oil tank 0,5 Ltr
Control: remote control manually operated
4-button switch 24 V
Mains 220/110 V
50 Hz
Extension cord (cupper wire) 3x2,5 Mm2
Extension cord length 25 Mtr
