Mounting the bracket for the emergency stop on the FlexPendant holder
The FlexPendant holder is shipped with a default assembly without the bracket for
the emergency stop assembled to the holder. They are separated as two parts.
xx2100000767
Use this procedure to mount the bracket for the emergency stop to the FlexPendant
holder.
Note/illustrationAction
xx2000002356
Remove the four screws.1
Separate the rear part from the FlexPend-
ant holder.
2
Continues on next page
Product manual - OmniCore C90XT 59
3HAC073706-001 Revision: E
© Copyright 2020-2021 ABB. All rights reserved.
3 Installation and commissioning
3.4.2 Mounting the FlexPendant holder
Continued
