Function name Signal type Signal name Description
SSCBR.1.NO_OPR Number of CB operation cycle
SSCBR.1.OPENPOS CB is in open position
SSCBR.1.OPR_ALM Number of CB operations
exceeds alarm limit
SSCBR.1.OPR_LO Number of CB operations
exceeds lockout limit
SSCBR.1.PRES_ALM Pressure below alarm level
SSCBR.1.PRES_LO Pressure below lockout level
SSCBR.1.SPR_CHR_ALM Spring charging time has
crossed the set value
SSCBR.1.TRV_T_CL_ALM CB close travel time exceeded
set value
SSCBR.1.TRV_T_OP_ALM CB open travel time exceeded
set value
Station battery supervision
(SPVNZBAT)
Binary inputs SPVNZBAT.1.AL_UHIGH Alarm when voltage has
exceeded higher limit for a set
time
SPVNZBAT.1.AL_ULOW Alarm when voltage has been
below lower limit for a set time
SPVNZBAT.1.ST_ULOW Start signal when battery
voltage drops below lower limit
SPVNZBAT.1.ST_UHIGH Start signal when battery
voltage exceeds upper limit
Automatic switch onto fault
logic (CVRSOF)
Binary inputs CVRSOF.1.OPERATE Operate
Local accelerat. logic
(DSTPLAL)
Binary inputs DSTPLAL.1.OPR_LOSSLOAD Operate by loss of load
DSTPLAL.1.OPR_Z_EXTN Operate by zone extension
Scheme communic. logic
(DSOCPSCH)
Binary inputs DSOCPSCH.CS Carrier Send signal
DSOCPSCH.LCG Loss of carrier guard signal
DSOCPSCH.OPERATE Trip output
DSOCPSCH.PRORX Carrier signal received or
missing carrier guard signal
Current reversal and WEI logic
(CRWPSCH)
Binary inputs CRWPSCH.1.OPR_WEI_C Operation of WEI logic in phase
C
CRWPSCH.1.OPR_WEI_B Operation of WEI logic in phase
B
CRWPSCH.1.OPR_WEI_A Operation of WEI logic in phase
A
CRWPSCH.1.OPR_WEI Operation of WEI logic
CRWPSCH.1.ECHO Carrier send by WEI logic
CRWPSCH.1.CR POR Carrier signal received
from remote end
Energy monitoring (EPDMMTR) Analog inputs EPDMMTR.1.EAFALM Alarm for active forward energy
exceed limit in set interval
Table continues on next page
