DNP3 device profile document
● Configurable as: only when reporting event data
(DLinkConfirm for each channel)
Requires application layer confirmation:
○ Never
○ Always
○ When reporting event data (slave devices only)
○ When sending multi-fragment responses (slave devices only)
○ Sometimes
● Configurable as: "Only when reporting event data", or "When reporting event data or multi-fragment messages."
(ConfMultiFrag for each master session)
Timeouts while waiting for:
Data link
confirm:
(tDLinkTimeou
t on
DNP3Channel
in PST)
● None ○ Fixed at ____ ○ Variable ○ Configurable
Complete
appl.
fragment:
○ None ○ Fixed at ____ ○ Variable ○ Configurable
Application
confirm:
(tApplConfTou
t on
DNP3Master
in PST)
○ None ○ Fixed at ____ ○ Variable ● Configurable
Complete
appl.
response:
● None ○ Fixed at ____ ○ Variable ○ Configurable
Others: • Transmission delay, configurable (tRxToTxMinDel for each channel).
• Select/Operate arm timeout, configurable (tSelectTimeout for each master session).
• Need time interval, configurable (tSynchTimeout for each master session).
• Unsolicited notification delay, configurable (tUREvBufTout1, tUREvBufTout2, tUREvBufTout3 for each master
session).
• Unsolicited response retry delay, configurable (tURRetryDelay for each master session).
• Unsolicited offline iInterval, configurable (tUROfflRtryDel for each master session).
Change events in the IED are generated by the device’s internal event system; they are not polled at a protocol-specific
scan rate. The periodicity for each point depends on the point’s data rate in the IED.
Binary change event scan period – see above
Double bit change event scan period – see above
Analog change event scan period – see above
Counter change event scan period – see above
Sends/Executes Control Operations:
WRITE binary
outputs
● Never ○ Always ○ Sometimes ○ Configurable
SELECT/
OPERATE
○ Never ● Always ○ Sometimes ○ Configurable
DIRECT
OPERATE
○ Never ○ Always ○ Sometimes ● Configurable
DIRECT
OPERATE -
NO ACK
○ Never ○ Always ○ Sometimes ● Configurable
Table continues on next page
