Technical data 115
Dimensions
Unit type
ACS880-207-…
Height 1 Height 2 Width 1 Width 2 Depth 1 Depth 2
mm in mm in mm in mm in mm in mm in
U
N
= 400 V (Range 380 … 415 V)
0420A-3 2145 84.5 2315 91.1 1000 39.4 1600 63.0 636 25 756 29.8
0580A-3 2145 84.5 2315 91.1 1000 39.4 1600 63.0 636 25 756 29.8
0810A-3 2145 84.5 2315 91.1 1000 39.4 1600 63.0 636 25 756 29.8
1130A-3 2145 84.5 2315 91.1 - - 2000 78.7 636 25 756 29.8
1330A-3 2145 84.5 2315 91.1 - - 2000 78.7 636 25 756 29.8
1580A-3 2145 84.5 2315 91.1 - - 2000 78.7 636 25 756 29.8
2350A-3 2145 84.5 2315 91.1 - - 2600 102.4 744 29.3 864 34
3110A-3 2145 84.5 2315 91.1 - - 2800 110.2 744 29.3 864 34
4620A-3 2145 84.5 2315 91.1 - - 4000 157.5 744 29.3 864 34
U
N
= 500 V (Range 380 … 500 V)
0400A-5 2145 84.5 2315 91.1 1000 39.4 1600 63.0 636 25 756 29.8
0530A-5 2145 84.5 2315 91.1 1000 39.4 1600 63.0 636 25 756 29.8
0730A-5 2145 84.5 2315 91.1 1000 39.4 1600 63.0 636 25 756 29.8
1040A-5 2145 84.5 2315 91.1 - - 1800 70.9 636 25 756 29.8
1420A-5 2145 84.5 2315 91.1 - - 2000 78.7 636 25 756 29.8
2120A-5 2145 84.5 2315 91.1 - - 2600 102.4 744 29.3 864 34
2800A-5 2145 84.5 2315 91.1 - - 2800 110.2 744 29.3 864 34
4150A-5 2145 84.5 2315 91.1 - - 4000 157.5 744 29.3 864 34
U
N
= 690 V (Range 525 … 690 V)
0310A-7 2145 84.5 2315 91.1 - - 1600 63.0 636 25 756 29.8
0370A-7 2145 84.5 2315 91.1 - - 1600 63.0 636 25 756 29.8
0540A-7 2145 84.5 2315 91.1 - - 1600 63.0 636 25 756 29.8
0720A-7 2145 84.5 2315 91.1 - - 1800 70.9 636 25 756 29.8
1050A-7 2145 84.5 2315 91.1 - - 1800 70.9 636 25 756 29.8
1570A-7 2145 84.5 2315 91.1 - - 2600 102.4 636 25 756 29.8
2070A-7 2145 84.5 2315 91.1 - - 2800 110.2 744 29.3 864 34
3080A-7 2145 84.5 2315 91.1 - - 3600 141.7 744 29.3 864 34
4100A-7 2145 84.5 2315 91.1 - - 5100 200.1 744 29.3 864 34
5130A-7 2145 84.5 2315 91.1 - - 5900 232.3 744 29.3 864 34
3AXD00000601909
Definitions
Height 1 Normal height
Height 2 Height with IP54 roof
Width 1 Low power multidrive
Width 2 With auxiliary control cubicle and incoming cubicle(s)
Depth 1 Without option +C128 Cooling air through bottom
Depth 2 If option +C128 Cooling air through bottom is selected due to extra air inlet channel at the bottom
