ABB DS201 - Page 15

15
Note: For dimensions, see page 60
Field of
application
Short circuit
breaking
capacity
EN 61009 Icn
Rated
breaking
capacity
(to earth) I
∆m
Thermomagnetic
release
characteristic
Rated
current In
Rated
sensitivity I
∆n
DS201 L
A, AC, APR
4,5 kA
4,5 kA
C
6...32 A
10, 30,
300 mA
DS201
A, AC, APR
6 kA
6 kA
B, C, D, K
1...40 A
10, 30,
100, 300,
1000 mA
DS201 M
A, AC,
APR, G
10 kA
6 kA
B, C
4...40 A
10, 30,
100,
300 mA
DS202C M
A, APR
10 kA
6 kA
B, C
6...32 A
10, 30,
300 mA
DS202C
A
6 kA
6 kA
C
6...32 A
30,
300 mA
DS202C L
A, AC
4,5 kA
4,5 kA
C
6...32 A
30 mA
