ABB GSec/T1 User Manual

11
10
11
8
9
5
6
4
12
13 14
2
1
3
15
7
GSec/IB switch-disconnectors
Fig. 6
Key
1 Disconnector
2 Lifting points
3 Earthing switch
4 Earthing switch transmission rod
5 Switch-disconnector-Earthing switch lever seat
6 Switch-disconnector lever seat
7 Terminal box for wiring auxiliary circuits
8 Disconnector position signalling seat
9 Earthing switch position signalling seat
10 Rating plate
11 Key locks
12 Voltage presence signalling lamps
13 Cable route of voltage presence signalling lamps
14 Fixed contacts
15 Main circuit connection points
