5.2. Types of switch-disconnectors and earthing switches

5.2.1. GSec/T1 and GSec/T2 switch-disconnectors

Key

1 Switch-disconnector

2 Lifting points

3 Switch-disconnector lever seat

4 Earthing switch lever seat

5 Switch-disconnector position signalling seat

6 Rating plate

Fig. 2

7 Key locks

8 Voltage presence signalling lamps

9 Cable route of voltage presence signalling lamps

10 Terminal box of auxiliary circuits

11 Earthing circuit connection point

12 Main circuit connection point
