647016/002 M3650 - 2000/05/24 ro-en - 5/40
CIRCUIT-BREAKER IEC 56
HD4 ... CEI 17-1
No. ... MASS ... kg
RATED VOLTAGE ... kV
IMPULSE WITHSTAND VOLTAGE ... kV
RATED FREQUENCY 50/60 Hz
RATED NORMAL CURRENT ... A
SHORT-TIME CURRENT (1 s) ... kA
CLOSING/OPENING TIME ... ms
ABSOLUTE SF6 PRESSURE AT 20 °C ... kPa
BREAKING CAPACITY ... kA
MAKING CAPACITY ... kA
AT VOLTAGE OF ... kV
OPERATION SEQUENCE 0-3MIN-CO-3MIN-CO
OPERATING MECHANISM IEC 56
--- ... CEI 17-1
No. ...
YC ... V —
YU ... V —
YO1 ... V —
H ... V —
M ... V —
Designed and manufactured by ABB T & D S.p.A. Div. Sace T.M.S.
Legenda
A Placuta de identificare intrerupator
B Placuta identificare mecanism de actionare
1 Tipul intrerupatorului
2 Standarde
3 Numar de serie
4 Caracteristicile intrerupatorului
5 Caracteristicile dispozitivelor auxiliare
Caption
A Circuit-breaker nameplate
B Operating mechanism nameplate
1 Type of apparatus
2 Symbols and compliance with Standards
3 Serial number
4 Circuit-breaker characteristics
5 Characteristics of the operating auxiliaries
1
A
B
3
4
5
2
INTRERUPATOR IEC 56
HD4 ... CEI 17-1
NR. ... MASA ... kg
TENSIUNEA NOMINALA ... kV
TENSIUNEA DE TINERE LA IMPULS ... kV
FRECVENTA NOMINALA 50/60 Hz
CURENTUL NOMINAL ... A
CURENTUL DE SCURTCIRCUIT (1 s) ... kA
TIMPUL DE INCHIDERE/DESCHIDERE ... ms
PRESIUNEA ABSOLUTA SF6 20 °C ... kPa
CAPACITATEA DE RUPERE ... kA
CAPACITATEA DE INCHIDERE ... kA
LA TENSIUNEA DE ... kV
SECVENTA DE OPERARE 0-3MIN-CO-3MIN-CO
MECANISMUL DE ACTIOANRE IEC 56
--- ... CEI 17-1
NR. ...
YC ... V —
YU ... V —
YO1 ... V —
H ... V —
M ... V —
Designed and manufactured by ABB T & D S.p.A. Div. Sace T.M.S.
1
A
B
3
4
5
2
Placuta de identificare
Fig. 1
Nameplate
3. Storage
When a period of storage is foreseen, (on request) our work-
shops can provide suitable packing for the specified storage
conditions.
On receipt the apparatus must be carefully unpacked and
checked as described in Checking on receipt (chap. 2).
If immediate installation is not possible, the packing must be
replaced, using the original material supplied.
La refacerea ambalajului trebuie introduse substante hygro-
scopice, cel putin un pachet la colet
Should the original packing not be available and immediate
installation is not possible, store in covered, well-ventilated,
dry, dust-free, non-corrosive ambients, away from any flamma-
ble materials and at a temperature between –5 °C and +45 °C.
In any case, avoid any accidental impacts or positioning which
stresses the structure of the apparatus.
3. Depozitarea
Daca se doreste o depozitare a echipamentelor pentru o
perioada mai lunga ambalarea intrerupatoarelor se poate face
(la cerere) intr-un ambalaj rezistent la conditiile de depozitare.
La receptie echipamentele trebuie despachetate cu atentie
iar receptia trebuie realizata in conformitate cu instructiunile de
la capitolul 2.
Daca instalarea echipamentelor nu se face imediat dupa re-
ceptionarea trebuie refacut ambalajul folosindu-se cel existent.
La refacerea ambalajului trebuie introduse substante hygro-
scopice, cel putin un pachet la colet.
In cazul in care ambalazul original nu se mai poate folosii,
iar instalarea echipamentelor nu se face imediat, se va asigura
spatiu de depozitare astfel, un loc acoperit, bine ventilat, uscat,
fara praf, fara agenti corozivi, departe de orice material infla-
mabil si cu temperatura cuprinsa intre –5 °C si +45 °C.
In orice caz, trebuie evitat impactul accidental al intrerupa-
toarelor.
