Operation Manual / TPS44-F.. - TPS61-F..
Disassembly and assembly 8
Disassembling and assembling
turbocharger
8.3 Page 99
© Copyright 2016 ABB. All rights reserved.
August 2017HZTL2412_ENRevision F
Installing compressor casing
τ Refit wall insert (77000) and O-ring (77005) in the reverse order.
NOTICE
O-rings
Used O-rings must always be replaced with new ones. O-rings are only
available as a set (see chapter Spare parts).
τ Refit diffuser in reverse order.
τ Fit compressor housing in reverse order.
τ Thoroughly clean fastening strips (72012) before fitting them.
Fitting the diffuser
