Operation Manual / TPL67-C.. - TPL71-C..
8 Disassembly and assembly / 8.9 Table of tightening torques
© Copyright 2020 . All rights reserved. HZTL2488_EN Rev.G March 2020
Tightening torques [Nm]
Part number TPL67-C TPL71-C
1 82005 M16x1.5
45
M16x1.5
45
3 72002 M10
50
M12
80
4 72027
with washer
M14
95
M16
125
5 72029
with washer
M14
30
M16
30
6 61037 M16
110
M18
160
6a 61090 M16
10
M18
15
7 61036 M16
30
M18
40
8 61059 M16
200
M18
280
9 42059 M12
80
M16
180
17 61044 M12
80
M14
130
21 61056 M12
105
M14
130
29 86505 M18x1.5
150
M18x1.5
150
