Operation Manual / TPL67-C.. - TPL71-C..
12 Spare parts / 12.1 Ordering spare parts
© Copyright 2020 . All rights reserved. HZTL2488_EN Rev.G March 2020
Spare parts set (97078) for turbine cleaning system (if provided)
CAUTION
Leaks
Improper assembly of the cleaning pipe and the nozzles can lead to
leaks and failure of the turbine cleaning system.
u Work on turbine cleaning system should be carried out only by an
ABB Turbocharging service station.
Axial gas inlet casing
Quantity Description Part number
6 Locking plate 51255
3 Gasket 52200
2 Hexagon-head screw 52204
2 Hexagon-head screw 52205
3 Nozzle 52208
2 Hexagon-head screw 52257
Radial gas inlet casing
Quantity Description Part number
4 Locking plate 51255
3 Gasket 52200
2 Hexagon-head screw 52204
2 Hexagon-head screw 52205
1 Nozzle 52208
1 Nozzle 52209
1 Nozzle 52210
2 Locking plate 52213
1 Hollow (banjo) screw 52219
2 Hexagon-head screw 52257
4 Verbus Ripp® Washer 52258
Page 120 / 125
