12 Spare parts / 12.2 View of turbocharger with part numbers
© Copyright 2020 . All rights reserved. HZTL2488_EN Rev.G March 2020
Part number Description
42012 (in customer spare part set) O-ring
51001 Gas inlet casing
51012 Segment
56001 Nozzle ring
61001 Gas outlet casing
61037 (in customer spare part set) Hexagon nut
61044 Hexagon-head screw
61050 (if provided) Gasket
61056 (in customer spare part set) Hexagon-head screw
61057 (in customer spare part set) Verbus Ripp® Washer
61058 (in customer spare part set) Verbus Ripp® Washer
61059 (in customer spare part set) Hexagon-head screw
63000 Turbine diffuser
68001 Foot at compressor end
68002 Foot at turbine end
68003 Slide plate
68006 Cup spring
68007 Bush
72000 Compressor casing
77000 Wall insert
77005 (in customer spare part set) O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
