4.4.2 Assembly
If the speed sensor is not fitted on the turbocharger, the following pro-
cedure must be adopted to fit it:
w Engine and turbocharger are not running.
w The turbocharger lubricating system is switched off.
u Remove screw plug (42047) from bearing casing.
NOTICE
Part position
The position of the screw plug for measuring the speed is marked "n"
on the bearing casing.
u Screw in speed sensor (86505) as far as it will go and tighten to
torque specified in table. (See chapter Table of tightening torques.)
u Connect speed sensor using cable connector (86515).
